DELTA C2000 series vfd750c43a 75kw inverter

Delta VFD750C43A

Specifications

Item Number: VFD750C43A

Manufacturer: Delta Products
Item Category: inverter
Subcategory: AC
Series: C2000
Nominal Input VAC: 460 Volts AC
Input Range VAC: 323 to 528 Volts AC
Amps (CT): 143 Amps
HP (VT): 100 Horsepower
Amps (VT): 150 Amps
Input Phase: 3
Operator Controls: Keypad Included
Braking Type: DC Injection;Dynamic Braking;AC Line Regenerative
Motor Control-Max Level: Closed Loop Vector
Closed Loop: Yes
AC Line Regenerative?: Yes
Dynamic Braking Trans?: Optional (External)
Frame Size: D
Height: 21.65 Inches
Width: 12.99 Inches
Depth: 10.83 Inches
