MT8102IE Weinview Weintek HMI touchscreen 10.1 inch
Weinview Human Machine Interface:
| MT8102iE Weinview HMI Touch Screen 10.1inch 1024x600 Ethernet replace MT8101iE MT8100iE |
1, package included:
1pcs MT8102iE human machine interface HMI touch screen new in box;
1pcs programming cable(Only offer it free when you ask for after order. Not ship it default. The communication cable is not included, if you need, please contact us and inquiry it)
The software is free(we can send it by email if you cant download it by yourself)
2, Performance specification
display | Display type | 10.1TFT |
resolution | 1204 x 600 | |
lightness (cd/m2) | 350 | |
contrast | 500:1 | |
backlight | LED | |
Backlight life | More than 50,000 hours | |
color | 16.7M | |
Touch panel | Four-wire analog resistance type | |
memory | Flash (MB) | 128 |
DRAM (MB) | 128 | |
processor | 32Bit RISC Cortex-A8 600MHz | |
communication | SD | N/A |
USB Host | USB 2.0 x 1 | |
USB Client | N/A | |
Ethernet | 1 RJ45 port(10/100 Base-T) | |
COM | Con.A: COM2:RS-485 2w/4w,Com3:RS-485 2w. Con.B:COM1:RS232/COM3:RS232 | |
Calendar | Built in | |
power | input | 2420%VDC |
power | 400mA 24V | |
Isolated power | Built in | |
Pressure-proof | 500VAC (1 munite) | |
Insulating resistance | 50MW at 500VDC | |
Quake-proof | 10 to 25Hz(X,Y,Z 2G 30munites) | |
Specifications | Sheathing material | ABS |
Outside measurement | 271x 213 x36.4mm | |
Opening size(mm) | 260x 202mm | |
Weight(kg) | 1.3 kg | |
Operating Environment | Protection level | NEMA4/IP65 |
Storage Temperature | -20 to 60C (-4to 140F) | |
Operating Temperature | 0to 50C(32to 122F) | |
Operating Humidity | 10% to 90% 40C | |
CE Certification | CE | CE marked |
Software | EasyBuilder Pro |
